LED DOWNLIGHT · GL SERIES
IRIS-G Grille Tiltable Downlight
10W-50W · 1400-7200lm · grille downlight with single/double heads for retail displays.
Home / Product / Led Downlight / IRIS-G
IRIS-G grille tiltable downlight in white finish — single and double heads for retail displays.
IRIS-G Grille Tiltable LED Downlight
GL series · single/double heads · 10W-50W · CRI90 · 15/24/38/60°
The IRIS-G GL is a grille tiltable LED downlight for retail displays, fitting one or two aimable heads into a single ceiling opening so jewelry counters, watch walls and boutique shelves each get their own beam without extra cutouts.
Each head of this adjustable grille downlight pulls down from the trim and turns 350 degrees with a 90-degree tilt, pairing up to 145lm/W efficacy with CRI 90 or above for true color on gems, fabrics and cosmetics.
- R/S/double heads, 10W-50W, up to 7200lm
- 145lm/w, CRI ≥90, 15°/24°/38°/60° beam
- 350° rotation + 90° tilt, retractable body
- White/Black finishing, 220-240V AC
Datasheet
LC-GL full specifications
| LC-GL6499-10W | |||
|---|---|---|---|
| Model | LC-GL6499-R10W | LC-GL6499-S10W | LC-GL6499-2X10W |
| Wattage | 10W ±5% | 10W ±5% | 10W*2 ±5% |
| Input Voltage | 220-240V AC 50/60Hz | 220-240V AC 50/60Hz | 220-240V AC 50/60Hz |
| Lumen Output | 1400lm ±5% | 1400lm ±5% | 2800lm ±5% |
| Size (Ø x H) | Ø90*H95 | 90*90*H95 | 90*170*H95 |
| CRI | ≥90 | ≥90 | ≥90 |
| Beam Angle | 15°/24°/38°/60° | 15°/24°/38°/60° | 15°/24°/38°/60° |
| Finishing | White/Black | White/Black | White/Black |
| Cutout | Ø75mm | 75x75mm | 75x155mm |
| LC-GL6499-15W | |||
|---|---|---|---|
| Model | LC-GL6499-R15W | LC-GL6499-S15W | LC-GL6499-2X15W |
| Wattage | 15W ±5% | 15W ±5% | 15W*2 ±5% |
| Input Voltage | 220-240V AC 50/60Hz | 220-240V AC 50/60Hz | 220-240V AC 50/60Hz |
| Lumen Output | 2100lm ±5% | 2100lm ±5% | 4200lm ±5% |
| Size (Ø x H) | Ø110*H120 | 110*110*H120 | 110*210*H120 |
| CRI | ≥90 | ≥90 | ≥90 |
| Beam Angle | 15°/24°/38°/60° | 15°/24°/38°/60° | 15°/24°/38°/60° |
| Finishing | White/Black | White/Black | White/Black |
| Cutout | Ø95mm | 95x95mm | 95x190mm |
| LC-GL6499-25W | |||
|---|---|---|---|
| Model | LC-GL6499-R25W | LC-GL6499-S25W | LC-GL6499-2X25W |
| Wattage | 25W ±5% | 25W ±5% | 25W*2 ±5% |
| Input Voltage | 220-240V AC 50/60Hz | 220-240V AC 50/60Hz | 220-240V AC 50/60Hz |
| Lumen Output | 3600lm ±5% | 3600lm ±5% | 7200lm ±5% |
| Size (Ø x H) | Ø130*H140mm | 130*130*H140mm | 253*130*H140mm |
| CRI | ≥90 | ≥90 | ≥90 |
| Beam Angle | 15°/24°/38°/60° | 15°/24°/38°/60° | 15°/24°/38°/60° |
| Finishing | White/Black | White/Black | White/Black |
| Cutout | Ø115mm | 115*115mm | 115*230mm |
Why IRIS-G for Retail Displays
Two aimable heads in one ceiling opening
One IRIS-G grille opening holds one or two retractable heads, each panning 350° and tilting 90°
Jewelry cases, watch walls and layered shelf runs ask for two or three spots from a single ceiling position, and single-head downlights answer that by cutting more holes. The IRIS-G GL double-head grille spotlight carries one or two independently aimable heads in one opening: point both at one hero piece for double punch, or split them across neighboring displays when the planogram changes. Counters needing only one accent point from a single trim cost less with the recessed single-head downlight for single accent points — for one point see IRIS-R, if two spots from one cutout see IRIS-G.
Shared light quality keeps the family mixable. Every IRIS-G head delivers up to 145lm/W with CRI 90 or above, so gold reads warm, diamonds throw fire and packaging whites stay neutral under the same ceiling. Four optics — 15° for gemstone pinspots, 24–38° for watch walls and shelf wash, 60° for general fill between accent points — ship across single and double heads alike. Checkout lanes and fitting rooms where shoppers linger under the light want calm instead of punch: give those zones the fixed anti-glare downlight for lingering zones — for accent see IRIS-G, if comfort see DL01.
The retractable drop is what makes resets tool-free. Each head pulls down from the trim, pans a full 350 degrees and tilts 90 degrees by hand, so an evening window change needs no ladder work on wiring and no second fixture. That is the IRIS-G rule for retail displays: one grille opening, up to two beams, re-aimed in minutes for whatever lands on the counter next.
| Model | Form | Heads | Best for |
|---|---|---|---|
| IRIS-G GL | Recessed grille, retractable | 1–2 heads, 350° + 90° | Jewelry & multi-point counters |
| IRIS-R RD | Recessed single head | 1 head, 90° tilt | Single-point walls & features |
| IRIS-S SL | Surface-mounted head | 1 head, no cutout | Solid slabs with no opening |
| GLOW-D DL01 | Recessed fixed head | Fixed, UGR22 | Lingering & comfort zones |
Size the Light to the Counter
Single or double heads for 2.6–4m retail floors
One grille family spans 1400lm single spots to 7200lm double heads — pick head count by counter width
Pick head count by counter width first. A single head (10–25W, 1400–3600lm) covers narrow shelf runs, fitting-room ends and small wall features; a double head (2×10–2×25W, up to 7200lm) takes wide jewelry counters, watch walls and island displays where two beams from one opening beat two separate cutouts. Solid concrete slabs that accept no cutout at all cannot take any grille frame — those ceilings want the surface-mounted tiltable downlight for solid ceilings from the same 145lm/W family instead.
Then set beams by task. A 15° pinspot picks out a ring or a watch face, 24–38° washes shelf rows and wall graphics, and 60° fills the gaps between accent points so the ceiling never goes patchy. Across a full store the IRIS-G grille light never works alone — plan single and double heads inside the full LED downlight family for commercial projects with recessed, surface, grille and fixed heads sharing one light quality.
FAQ
Grille downlight answers for retail display projects
Two aimable beams from one ceiling opening — the IRIS-G GL grille frame carries single or double retractable heads, each panning 350 degrees and tilting 90 degrees by hand, with up to 145lm/W efficacy and CRI 90 or above for true color on gems and fabrics.
Choose by counter width, not by taste — a single IRIS-G head suits narrow shelf runs and small wall features, while a double head covers wide jewelry counters and watch walls with two independently aimed beams from one cutout. The IRIS-G GL double range runs 2×10W (2800lm) to 2×25W (7200lm).
Aim a 15° pinspot at rings, watches and mannequin faces, wash shelf rows and wall graphics with 24°–38°, and open to 60° for general fill between accent points. The IRIS-G GL ships exactly this 15/24/38/60° set across single and double heads.
Match the datasheet ladder to the room: 10W (1400lm, cutout 75mm) for low corners, 15W (2100lm, cutout 95mm) for standard 2.6–3m shop ceilings, 25W (3600lm, cutout 115mm) for 3–4m sales floors, and the 2×25W double head (7200lm, cutout 115×230mm) for wide high counters.
Fully by hand with no tools — each IRIS-G head pulls down from the grille trim, pans 350 degrees and tilts 90 degrees, then holds its position — an evening window reset takes minutes with no electrician call-out.
It delivers up to 145lm/W with CRI 90 or above, so colors render true while lighting power stays low across long retail hours. The IRIS-G GL holds this combination from the 10W single head all the way to the 2×25W double head at 7200lm.
Pick 3000K warm white for cozy boutiques, 4000K neutral for balanced floors, 6000K cool white for crisp displays, and a meat-spectrum option for food counters — all in White or Black trims. The IRIS-G GL carries every CCT across the full 10–50W single/double range.
Yes — runs on standard 220–240V AC circuits with spring-clip mounting into the listed cutouts from 75mm singles to the 115×230mm double frame, so single and double heads retrofit without special drivers.
